	QFD-100
	Folding High Speed Door
Max.dimensions	W6000mm x H6000mm
Opening speed Closing speed	1m/s settable 0.8m/s settable
Drive Technology	Side guide and Lateral driving belt
Drum	Steel-30mm solid steel
Curtain	Imported material high density PVC1.5mm +Aluminum alloy horizontal Rib+strap
Self-repairing	Non
Wind load	Class 2
Side guides and cover	Folded steel, galvanised before cutting and folding. Full covers standard. Option: stainless steel
Motor	Servo motor 1.5~2.2KW,IP54/IP65
Control Box	Circuit breaker, general divider, adjustable timer, push button for opening and reset and emergency stop. Frequency inverter.
Standard detectors	Infrared barrier: 300 mm from the floor.Wireless detector (WDD),Safety airbag edge protection
Actuation options	Push Buttons,Remote Close magenet coil,Rfid,Radar(options)
Power supply Frequency	1-phase-220v, 3phase-380v,50-60 Hz
Advised operating temperature	- 5 °C up to + 45 °C

Fast folding fabric doors are one of our special doors that we offer to customers in very busy places. It has satisfied our customers who use our door with its comfort and insulation. These doors, which can be used for many years, are generally used in industry. It allows you to enter and exit easily with fast opening time without any trouble.

Generally, the PVC fabric door can be used too much due to the intensity of the work. Therefore, the security of the door is at the forefront for us. Cutedoor doors do not compromise in terms of security.

Cutedoor are manufactured under CE Standard.
